Performance Chip Tuning for Volvo S60 II

The short answer

Volvo S60 II: 18 engines — 12 gas and 6 diesel. Gains run from +32 to +65 hp, with up to +108 Nm more torque. GAN GTL from 219 EUR, GAN GT from 329 EUR.

18

engines

12 gas · 6 diesel

+65hp

best in this generation: 2.0 T5 239 → 304 hp

gain range +32…+65 hp

+108Nm

max torque gain

2.4 D5, GT

from 219EUR

tuning module price

GAN GTL from 219 EUR · GAN GT from 329 EUR

Horsepower and torque gains

All Volvo S60 II engines: exact gains

STOCK output, output with GAN, gain and price for each module. Diesel and gasoline engines are listed separately.

Engine	STOCK → with GAN	Gain	Tuners and prices
Diesel · 6 engines
2.0 D3163 hp / 400 Nm	163 hp210 hp / 505 Nm	+47 hp+105 Nm	GTL — 249 EUR · 203 hp GT — 399 EUR · 210 hp	Select →
2.0 D4163 hp / 400 Nm	163 hp210 hp / 505 Nm	+47 hp+105 Nm	GTL — 249 EUR · 203 hp GT — 399 EUR · 210 hp	Select →
2.4 D5205 hp / 420 Nm	205 hp246 hp / 528 Nm	+41 hp+108 Nm	GTL — 249 EUR · 240 hp GT — 399 EUR · 246 hp	Select →
2.4 D5215 hp / 420 Nm	215 hp256 hp / 528 Nm	+41 hp+108 Nm	GTL — 249 EUR · 250 hp GT — 399 EUR · 256 hp	Select →
2.0 D3136 hp / 350 Nm	136 hp176 hp / 445 Nm	+40 hp+95 Nm	GTL — 219 EUR · 170 hp GT — 329 EUR · 176 hp	Select →
1.6 D2114 hp / 270 Nm	114 hp148 hp / 349 Nm	+34 hp+79 Nm	GTL — 219 EUR · 143 hp GT — 329 EUR · 148 hp	Select →
Gasoline · 12 engines
2.0 T5239 hp / 320 Nm	239 hp304 hp / 413 Nm	+65 hp+93 Nm	GTL — 249 EUR · 294 hp GT — 399 EUR · 304 hp	Select →
2.0 T203 hp / 300 Nm	203 hp260 hp / 385 Nm	+57 hp+85 Nm	GTL — 249 EUR · 251 hp GT — 399 EUR · 260 hp	Select →
1.6 T4179 hp / 240 Nm	179 hp230 hp / 312 Nm	+51 hp+72 Nm	GTL — 249 EUR · 222 hp GT — 399 EUR · 230 hp	Select →
2.0 T180 hp / 240 Nm	180 hp231 hp / 312 Nm	+51 hp+72 Nm	GTL — 249 EUR · 223 hp GT — 399 EUR · 231 hp	Select →
2.0 T4179 hp / 240 Nm	179 hp230 hp / 312 Nm	+51 hp+72 Nm	GTL — 249 EUR · 222 hp GT — 399 EUR · 230 hp	Select →
2.0 T5214 hp / 300 Nm	214 hp259 hp / 363 Nm	+45 hp+63 Nm	GTL — 249 EUR · 253 hp GT — 399 EUR · 259 hp	Select →
1.6 T3150 hp / 240 Nm	150 hp193 hp / 312 Nm	+43 hp+72 Nm	GTL — 249 EUR · 187 hp GT — 399 EUR · 193 hp	Select →
2.0 T5245 hp / 350 Nm	245 hp287 hp / 410 Nm	+42 hp+60 Nm	GTL — 249 EUR · 279 hp GT — 399 EUR · 287 hp	Select →
2.5 T5249 hp / 360 Nm	249 hp291 hp / 421 Nm	+42 hp+61 Nm	GTL — 249 EUR · 284 hp GT — 399 EUR · 291 hp	Select →
2.0 T4190 hp / 300 Nm	190 hp230 hp / 363 Nm	+40 hp+63 Nm	GTL — 249 EUR · 224 hp GT — 399 EUR · 230 hp	Select →
2.0 T6238 hp / 320 Nm	238 hp278 hp / 374 Nm	+40 hp+54 Nm	GTL — 249 EUR · 271 hp GT — 399 EUR · 278 hp	Select →
1.5 T3152 hp / 240 Nm	152 hp184 hp / 290 Nm	+32 hp+50 Nm	GTL — 249 EUR · 179 hp GT — 399 EUR · 184 hp	Select →

stock powergain with GAN

Each engine gets its own performance chip: GAN GT / GTL or GAN GA / GA+. Prices are per performance chip and include the current discount.

All Volvo S60 generations Volvo S60 (I) ->2010

Not sure which engine you have?

The badge alone isn’t enough: in this generation, the same engine came with different horsepower ratings, each with its own calibration. Check the horsepower in your owner’s manual or vehicle documents and find the matching row.

Same badge, different factory power outputs in this generation:

2.0 D3 136 / 163 hp2.4 D5 205 / 215 hp2.0 T5 214 / 239 / 245 hp2.0 T 180 / 203 hp2.0 T4 179 / 190 hp

GAN tuning module for the Volvo S60 II

Volvo S60 II tune: what changes

The module plugs in between the sensors and the engine control unit (ECU) and adjusts their signals. It never rewrites your ECU software: your factory warranty is preserved, and the module can be removed at any time.

Bluetoothswitch modes from your phone
18 mapsto fine-tune your engine

15 minutesplug-and-play install
IP67water and dust protection

+65 hpbest in this generation
2.0 T5 239 hp → 304 hp. The other engines gain +32 hp and up; check the table for each one.
+108 Nmfor diesels
Diesels gain mostly torque: +79 to +108 Nm for towing and hauling.
GAN APPpower control via smartphone
Switch between SPORT, DYNAMIC, ECO and STOCK in the GAN app.
50 daystest drive
Enhanced performance or your money back, excluding shipping costs.

Prices for the Volvo S60 II

GAN GT from 329 EUR GAN GTL from 219 EUR

Find your engine in the table

FAQ

Volvo S60 II tuning FAQ

Which tuner do I need for my Volvo S60 II?

Every engine in this generation is turbocharged, so you’ll want the GAN GT or GAN GTL. Find your engine in the table above – each row shows the tuner and the price.

Is a tuning module the same as a Stage 1 tune?

Not quite. Stage 1 usually means an ECU flash tune without replacing any parts. The tuning module also works without replacing parts, but it does not change the ECU software: it adjusts the sensor signals, comes off in about a minute, and the OFF button in the app restores the factory settings.
